Solplanet Smart Meter DTSU666 100A/40mA / Precise Energy Accounting for 3-Phase Systems
The Solplanet Smart Meter of the DTSU666 series is a highly precise three-phase energy meter that is essential for controlling zero injection and visualizing real-time energy parameters in self-consumption PV systems. The included current transformers (CTs) enable simple and accurate indirect measurement up to 100 A.
Highlights
- Accuracy Class 1: Highly precise measurement across the entire operating range.
- Includes 3 Current Transformers (100A/40mA): Ready for immediate use for indirect measurements.
- Export Limitation Control: Essential for compliance with grid injection rules.
Technical Data
| Property | Value |
|---|---|
| Grid Type | 3P4W (Three-phase with Neutral Conductor) |
| Max. Current Range | 0 to 100 A (with CTs) |
| Interface | RS485 (Modbus-RTU) |
| Mounting | DIN35 Rail |
| Dimensions (W/H/D) | 100 x 72 x 65.5 mm |
| Measurement Accuracy | > Class 1 |
Scope of Delivery
- Solplanet Smart Meter DTSU666
- 3 x Current Transformers 100A/40mA (5m cable)
- RS485 cable (10m)
- Installation Guide
Notes
The meter is required for dynamic power limitation in combination with compatible Solplanet inverters.
